Specs
- UPC 193308119649
- Onboard Intelligence RED Technology
- Starter Electric
- Steering Control Hydraulically dampened twin levers, adjust fore and aft. Adjustable dampeners (3 positions) to customize drive responsiveness. Also adjustable to 2 height positions.
- Caster Forks .50" thick caster yoke arms.
- Front Caster Tires 13 x 6.5-6, smooth-tread, semi-pneumatic.
- Drive Tires 24 x 12.0-12, 4-ply Turf Master®
- Parking Brake Lever-actuated disc brake.
- Tractor Frame Unibody, welded, heavy-duty 1.5" x 3" tubular steel.
- Blade Spindles No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft, double row bearings, top and bottom, and splined blade driver.
- Electrical 12-volt battery with 40-amp alternator.
- Standard Features Engine hour meter and cup holder
- Seat Deluxe, two-tone, bolstered suspension seat with Elastomeric Vibration Control material. Mounted on innovative Seat Isolation System that provides operator isolation in all three planes of motion as well as fore-aft slide and seat flip-up.
- Engine Brand Kohler
- Engine Brand Kohler
- Transmission Speeds Infinitely Variable
- Engine Model ECV980
- Engine Displacement 999
- Engine Series Command Pro™ EFI
- Fuel System Electronic Throttle Body
- Speed Infinitely variable speed selection from 0–10.5 mph (16.8 kmph) forward, 0–6.0 mph (9.7 kmph) reverse
- Transmission Hydrostatic
- Drive Hydro-Drive
- Engine Spec 3018
- Engine Speed 3,650 RPM
- Air Filter Heavy-duty canister air filtration system
- Fuel Capacity 12-gallon (45.4-L), single fuel tank with single fill location.
- Drive Description Two Exmark exclusive Parker unitized pump and wheel motor systems with no hoses, integrated cooling fans, shock valve, 1.7-quart integrated reservoir, spin-on filter and heavy-duty components. 16 cc pumps and 18 cubic inch motors.
- Fuel Type Gas EFI
- PTO Engagement MagStop Electromagnetic 250-ft-lb clutch with spot brake
- Drive Wheel Release Allows unit movement without engine running.
- Fuel Indicator Yes - electronic Sender
- Deck Lift Electric over hydraulic push button control
- Carb Compliant No
- Safety Package Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.
- ROPS 2-post foldable ROPS standard with seat belt and latch.
- Deck Style Floating Deck
- Deck Style Description Full-floating UltraCut Rear Discharge Deck. Finish cut baffles installed standard, rear discharge improvement baffles available via kit.
- Width / Cutting Deck 96"
- Deck Construction 7-gauge high strength alloy top that is formed and continuously seam welded, with 7-gauge high strength alloy side skirt.
- Cutting Heights 1.0" (2.5 cm) to 5.5" (11.8 cm) in 0.25" (0.64 cm) increments.
- Blade Tip Speed Approximately 18,500 fpm
- Blades 4 Blades at 24.50" Length
- Width 101.3 in. (257.0 cm), 72.5 in. @ 3 in. HOC when folded
- Height 70.5 in. (179.1 cm)
- Length 95.8 in. (243.3 cm)
- Curb Weight 2200
